Standard Dimensions: Sweep radius 1500mm – Suction pipe diameter 75mm – Duct connection diameter 100mm
It can be mounted on the ceiling, this local air suction arm can be used by bringing it to the desired position. Laboratory, workshop, etc. with point polluted air outlet. are mounted on the ceiling. It is a perfect solution to remove polluted or toxic air from the environment with a suitable fan motor and exhaust air duct.
After the joints are easily brought to the desired position, the ears can be fixed by tightening. Tri-joint arms are made of anodized aluminum. It has a reverse-reaction spring main suction pipe that will prevent the arm from sagging. Ceiling mount is also made of anodized aluminum. It has a length of up to 2m. Ceiling mounting feet can be shortened by cutting as needed. The joint parts of the local air suction arm are made of chemical resistant PP plastic. There is a transparent polycarbonate hood on the suction mouth. There is a manual air flap that opens and closes the air suction amount. The scanning radius of the local absorber is 1500mm. Thus, it can be used effectively in a circle with a diameter of 3m.
