HOMOGENIZORS
HOMMAK C – HM1

Homogenizer C – HM1

“HIGH PRESSURE LAB SCALE HOMOGENIZER”

“FREE” SPARE PARTS WITH MACHINE :

  • 1 pcs of plungers
  • 1 set of packing seals
  • 1 set of suction valves and valve seats
  • 1 set of gaskets of suction and delivery valve
  • 1 set of delivery valves and valve seats
  • 1 set of Suction and delivery valve springs
  • 1 pcs of Homogenizing passage head
  • 1 pcs of impact head
  • 1 pcs of impact ring

Lab Homogenizer and Hommak Homogenizer;

1.Laboratories typically conduct product testing in the pressure range of 0-1.000Bar.

800 Bar is an extremely high pressure figure, and if a particular super duplex forged steel material is not utilized for the Block System, it might lead to major issues down the road, such cracking. Hommak imports Monoblocks from Europe, which we then process using our CNC machinery. With regard to cracking, we provide a 10-year guarantee on the Super Duplex Monoblock.

  1. Manufacturers of laboratory-style homogenizers come from Europe, the USA, and Asia. All of them, with the exception of us, produce homogenizers with one or two pistons (plungers). However, the other substantial industrial homogenizers in factories have three pistons (plungers). As a consequence, the outcomes you get in your laboratory and those of your company will be quite different. (Won’t have the same impact or provide the same micronization effects.) On the other hand, our Hommak Lab Scale Homogenizers include 3 pistons (plungers) as well, and the outcomes will be consistent with those of your other Industrial Type homogenizers from the company.



  1. Hommak homogenizers also run at the lowest RPM in the world since they are gear reducer powered. It lengthens the time between spare component replacements while allowing the homogenizer to operate more pleasantly.



  1. All dairy products (milk, ice cream, drinkable yoghurt, protein drinks, milk shakes, etc.), chocolate sauce, topping sauces, ketchup, mayonnaise, tahini, yeast-bacteria cell disruptions, etc. may be passed through our 3-piston Hommak Laboratory Homogenizer with ease.



GENERAL TECHNICAL SPECIFICATIONS :

  • Gear Reducer driven system to lowest working RPM.
  • Stainless Steel Plungers can be Chrome / Cobalt Carbide / Tungsten Carbide / Ceramic coated
  • Homogenizing Valve Group can be Tungsten carbide / Zirconium Ceremic / Silicon Nitride Ceramic
  • Control switch, Solenoid valve for cooling water
  • Lubrication System run by manual strikes
  • Stainless Steel Electrical Panel Board can be IP55 , IP65 , IP66 , ATEX (Exproof)
  • Safety overpressure Relief valve
  • Running time indicator to arrange maintenance period
  • Sanitary Analog diaphragm or Digital pressure gauge 0-600Bar, 0-1000Bar, 0-2000Bar
  • Homogenizer valve with pneumatic system adjustment
  • Specially designed casting body which comprises carriage parts
  • CE Declaration of Conformity; Machine safety directive 2006/95/EC
  • AISI304 Stainless Steel Frame with special sanding.
  • Suction & Delivery valves and Valve seats can be Cobalt carbide / Tungsten Carbide
  • Compression Monoblock head : Forged special stainless steel MONOBLOCK (10 years warranty)
  • IE2 / IE3 Type AC motor drive through V belts and pulleys integrated gearbox
  • Made in Turkey
