HOMOGENIZORS
S-HM5

Homogenizer

“HIGH PRESSURE HOMOGENIZER”

“FREE” SPARE PARTS WITH MACHINE :

  • 1 pcs of plungers
  • 1 set of packing seals
  • 1 set of suction valves and valve seats
  • 1 set of gaskets of suction and delivery valve
  • 1 set of delivery valves and valve seats
  • 1 set of Suction and delivery valve springs
  • 1 pcs of Homogenizing passage head,
  • 1 pcs of impact head
  • 1 pcs of impact ring
Homogenizer
Homogenizer

HOMMAK S-HM5

  • LONGER SHELF LIFE
  • BETTER BRIX
  • LESS SEDIMENTATION
  • IMPROVED COLOUR
  • IMPROVED FLAVOUR

GENERAL TECHNICAL SPECIFICATIONS :

  • Gear Reducer driven system to lowest working RPM.
  • Stainless Steel Plungers can be Chrome / Cobalt Carbide / Tungsten Carbide / Ceramic coated
  • Homogenizing Valve Group can be Tungsten carbide / Zirconium Ceremic / Silicon Nitride Ceramic
  • Control switch, Solenoid valve for cooling water
  • Lubrication System run by manual strikes
  • Stainless Steel Electrical Panel Board can be IP55 , IP65 , IP66 , ATEX (Exproof)
  • Safety overpressure Relief valve
  • Running time indicator to arrange maintenance period
  • Sanitary Analog diaphragm or Digital pressure gauge 0-600Bar, 0-1000Bar, 0-2000Bar
  • Homogenizer valve with pneumatic system adjustment
  • Specially designed casting body which comprises carriage parts
  • CE Declaration of Conformity; Machine safety directive 2006/95/EC
  • AISI304 Stainless Steel Frame with special sanding.
  • Suction & Delivery valves and Valve seats can be Cobalt carbide / Tungsten Carbide
  • Compression Monoblock head : Forged special stainless steel MONOBLOCK (10 years warranty)
  • IE2 / IE3 Type AC motor drive through V belts and pulleys integrated gearbox
  • Made in Turkey
